Tourlock Type |
D Diameter (mm) |
A Canopy height (mm) |
B High under Canopy (mm) |
C Throat Opening (mm) |
E Installation width (mm) |
F Passage width (mm) |
Capacity / minute |
|
180+90 |
1600 |
200 |
2198 |
1038 |
1677 |
759 |
2 x 20 |
|
180+90 |
1800 |
200 |
2198 |
1180 |
1877 |
859 |
2 x 20 |
|
180+90 |
2000 |
200 |
2198 |
1321 |
2077 |
959 |
2 x 20 |
|
180+90 |
2200 |
200 |
2198 |
1463 |
2277 |
1059 |
2 x 20 |
|
120 |
1600 |
200 |
2198 |
684 |
1677 |
759 |
1 x 15 |
|
120 |
1800 |
200 |
2198 |
784 |
1877 |
859 |
1 x 15 |
|
120 |
2000 |
200 |
2198 |
884 |
2077 |
959 |
1 x 15 |
|
120 |
2200 |
200 |
2198 |
984 |
2277 |
1059 |
1 x 15 |
|
120M |
1500 |
300 |
2198 |
634 |
1577 |
709 |
1 x 15 |
|
120M |
1600 |
300 |
2198 |
684 |
1677 |
759 |
1 x 15 |
|
120M |
1800 |
300 |
2198 |
784 |
1877 |
859 |
1 x 15 |
Revolving Door Technical specifications:
| Power supply | 200-240 VAC,50/60Hz
|
| Motor | AC motor,3-phase
|
| Power Consumption
Operating Stationary |
100 W 95 W |
| Fuse | External power supply fused with 16 A Slow |
| Compatibility | The Tourlock is compatible with the most access control system by using potential free contacts. |
Remarks: Design and specification are subject to change without notice. Products are tailored to meet your requirement.
